   E-Type Circlips


E-Type Circlips
quote1
Outer Diameter
1.5mm to 24mm

Thickness
0.4mm to 2mm



bullet1
Material and Hardness of
logo
E-Type Circlips :

All the Circlips are manufactured from spring steel of grade such as 70C6 or 75C6 confirming to IS : 2507 - 1975 specification for cold rolled steel strips for springs (first revision).

Hardness of Circlip is between 460 to 580 HV (Corresponding to 46 to 54 HRC)

bullet1
Surface Finish of
logo
E-Type Circlips :

Unless the purchaser specifies any alternative finish, the circlip shall be chemically or thermally blackened.


E-Type Circlips


Nominal

Circlip

Shaft Groove

size

d4

A

S

Tol

D3

d2

m

Tol.  on

d1

Expanded

H10



on s

From

To

h11



m

0.8

2

0.58

0.20



1

1.4

0.8

0.24



1.2

3

1.01

0.30



1.4

2

1.2

0.34

± 0.02

1.5

4

1.28

0.40



2

2.5

1.5

0.44



1.9

4.5

1.61

0.50



2.5

3

1.9

0.54



2.3

6

1.94

0.60



3

4

2.3

0.64



3.2

7

2.70

0.60

± 0.02

4

5

3.2

0.64



4.0

9

3.34

0.70



5

7

4

0.74

± 0.03

5.0

11

4.11

0.70



6

8

5

0.74



6.0

12

5.26

0.70



7

9

6

0.74



7.0

14

5.84

0.90



8

11

7

0.94



8.0

16

6.52

1.00



9

12

8

1.05



9.0

18.5

7.63

1.10



10

14

9

1.15



10

20

8.32

1.20



11

15

10

1.25



12

23

10.45

1.30

± 0.03

13

18

12

1.35

± 0.06

15

29

12.61

1.50



16

24

15

1.55



19

37

15.92

1.75



20

31

19

1.80



24

44

21.88

2.00



25

38

24

2.05






header4
arrow
arrow
arrow

arrow

arrow

arrow

arrow

header6




AASRAA METAL FORMS PVT.LTD. : -7, Meenakshi Chambers, Goddev Rd.,  Bhayandar (E),
Thane - 401105, Maharashtra, India. Telephone - (022) 28191644 / 28192604 / 65777180 Mobile - + 91 9820094249
